HAVN BF 360 Flow Gaming PC Case – White High Airflow ATX Mid Tower

HAVN BF 360 Flow Gaming PC Case – White High Airflow ATX Mid Tower - Image 2

HAVN BF 360 Flow Gaming PC Case – White High Airflow ATX Mid Tower

High-airflow ATX mid-tower with GPU-focused air guide ramp and dual 180mm fans.
Ultra-quiet operation with premium FDB bearings and vibration isolation.
Minimalistic stone-textured front panel with SimpliCable routing system for a cleaner build.

Description
Specification

Category	Specification
Model	BF 360 Flow
Part Number	HVN-CA-BF360-03
Form Factor	Mid Tower
Material	SGCC sheet metal, tempered glass, ABS, Nylon, Silicon, Zinc alloy, NdFeB magnets
PC Case Dimensions (L x W x H)	515 x 254 x 522.6 mm
Net Weight	14.79 kg
Warranty	1 year
Notice	Warranty support is only available for orders shipped within the United States. Orders via forwarding services are not supported.Please review our full warranty terms for more information.
Front I/O	USB 3.2 Gen 2 Type-C x1USB 3.2 Gen 1 Type-A x2Audio Jack x1Power & Reset Button x1
Motherboard Support	E-ATX* / ATX / Micro-ATX / ITX*To install an E-ATX motherboard, the built-in GPU support bracket must be removed.
Expansion Slots	7
Fan Support	Maximum Amount: 6Top: 2 x 180 mm / 2 x 140 mm / 3 x 120 mmFront: 2 x 180 mmLeft: N/ARight: N/ABottom: N/ARear: 1 x 140 / 1 x 120 mm
Fan PWM Repeater	Fan Ports: 1 x PWM repeaters, 6 ports totalLocation: 1 x Cable Management TrayFan Connectors: 6 ports per repeater x 4-pin PWM(Connect your primary fan to the white port to control PWM signal. All other ports mirror the white port’s signal.)Fan Rated Voltage: 12VFan Safety Current: Up to 2.6A across 6 portsPower Connector: 1 x SATA PowerPower Safety Current: 1 x SATA connector power input, 12V → 2.6A (max)
CPU Tower Cooler Clearance	Height: Up to 195 mm.
Liquid Cooling Support	Top: 240 / 280 / 360 mmFront: N/ALeft: N/ARight: N/ABottom: N/AAIO Thickness Support: Up to 60mm
Graphics Card Clearance	Length: Up to 410 mmWidth: Up to 195 mm.
GPU Support	1 – 4.5 Slots
RAM Clearance	If the radiator & fans thickness is greater than 80 mm: 280 mm – 40 mm / 360 mm – 60 mm
Power Supply Support	ATXLength: Up to 200mm (Clearance – 260mm)
Storage	Right Mount: 2 Storage Bays: 2 x 3.5” / 4 x 2.5”Cable Management Tray: 1 Storage Bay: 1 x 3.5” / 2 x 2.5”Storage Bays Included: 2 x (2 x 3.5″ / 4 x 2.5″)
Dust Filter	Front: 1 (Built-in)Top: 1 (Built-in)Rear Bottom: 1 (Removable)
Pre-installed Fans	2x H18 Fan (Front) – Case Version1x H14 Fan (Rear) – Case Version(The Loopin™ System is available on the Retail Version only. Pre-installed case fans use single-female fan connectors.)
